TECHNICAL SPEC

Table size

770x970 mm

2 Mandrel Chuck Minimum Boring Capacity

45 mm

2 Mandrel Chuck Maximum Boring Capacity

1100 mm

Drill Capacity

10 mm

Mandrel chuck reclining depth angle

0º - 90º

Shield Working Size

900 mm

Motor Power

1.5 HP 1400 d/d

DIMENSIONS

Length

180 cm

Width

150 cm

Height

160 cm

Approx. Weight

425 kg
