TECHNICAL SPEC

SAW

Table size

520x850 mm

Saw Shaft Diameter

30 mm

Saw diameter, min

150 – 300 mm

Max cut with shield

650 mm

Saw shaft revolution

4500 rpm

Number of bearings

4 ea

Number of ball bearings

2 ea

Motor power

4 hp- 3000 d/d

PLANNING

Table size

430 x 2300 mm

Front plate length

1150 mm

Rear plate length

1150 mm

Ball diameter

110 mm

Number of blades

3 ea

Max mortising depth

15.5 mm

Table shield length

1500 mm

Motor power

4 hp – 3000 rpm

Number of bearings

2 ea

Number of ball bearings

2 ea

Number of revolutions

4500 rpm

DRILL

Table size

500 x 270 mm

Longitudinal motion

220 mm

Transversal motion

170 mm

Vertical motion

130 mm

Drill capacity

1 – 20 mm

Number of revolutions

4500 rpm

DIMENSIONS

Length

235 cm

Width

150 cm

Height

110 cm

Approx. weight

790 kg
